#include <juce_ScrollBar.h>
Classes | |
| class | Listener |
| struct | LookAndFeelMethods |
| class | ScrollbarButton |
Public Types | |
| enum | ColourIds { backgroundColourId = 0x1000300 , thumbColourId = 0x1000400 , trackColourId = 0x1000401 } |
| Public Types inherited from juce::Component | |
| enum class | FocusContainerType { none , focusContainer , keyboardFocusContainer } |
| enum | FocusChangeType { focusChangedByMouseClick , focusChangedByTabKey , focusChangedDirectly } |
Private Member Functions | |
| std::unique_ptr< AccessibilityHandler > | createAccessibilityHandler () override |
| void | handleAsyncUpdate () override |
| void | updateThumbPosition () |
| void | timerCallback () override |
| bool | getVisibility () const noexcept |
| Private Member Functions inherited from juce::Timer | |
| virtual | ~Timer () |
| void | startTimer (int intervalInMilliseconds) noexcept |
| void | startTimerHz (int timerFrequencyHz) noexcept |
| void | stopTimer () noexcept |
| bool | isTimerRunning () const noexcept |
| int | getTimerInterval () const noexcept |
| Timer () noexcept | |
| Timer (const Timer &) noexcept | |
Private Attributes | |
| Range< double > | totalRange { 0.0, 1.0 } |
| Range< double > | visibleRange { 0.0, 1.0 } |
| double | singleStepSize = 0.1 |
| double | dragStartRange = 0 |
| int | thumbAreaStart = 0 |
| int | thumbAreaSize = 0 |
| int | thumbStart = 0 |
| int | thumbSize = 0 |
| int | dragStartMousePos = 0 |
| int | lastMousePos = 0 |
| int | initialDelayInMillisecs = 100 |
| int | repeatDelayInMillisecs = 50 |
| int | minimumDelayInMillisecs = 10 |
| bool | vertical |
| bool | isDraggingThumb = false |
| bool | autohides = true |
| bool | userVisibilityFlag = false |
| std::unique_ptr< ScrollbarButton > | upButton |
| std::unique_ptr< ScrollbarButton > | downButton |
| ListenerList< Listener > | listeners |
Detailed Description
A scrollbar component.
To use a scrollbar, set up its total range using the setRangeLimits() method - this sets the range of values it can represent. Then you can use setCurrentRange() to change the position and size of the scrollbar's 'thumb'.
Registering a ScrollBar::Listener with the scrollbar will allow you to find out when the user moves it, and you can use the getCurrentRangeStart() to find out where they moved it to.
The scrollbar will adjust its own visibility according to whether its thumb size allows it to actually be scrolled.
For most purposes, it's probably easier to use a Viewport or ListBox instead of handling a scrollbar directly.
- See also
- ScrollBar::Listener
@tags{GUI}
Member Enumeration Documentation
◆ ColourIds
| enum juce::ScrollBar::ColourIds |
A set of colour IDs to use to change the colour of various aspects of the component.
These constants can be used either via the Component::setColour(), or LookAndFeel::setColour() methods.
- See also
- Component::setColour, Component::findColour, LookAndFeel::setColour, LookAndFeel::findColour
Constructor & Destructor Documentation
◆ ScrollBar()
| juce::ScrollBar::ScrollBar | ( | bool | isVertical | ) |
Creates a Scrollbar.
- Parameters
-
isVertical specifies whether the bar should be a vertical or horizontal
◆ ~ScrollBar()
|
override |
Destructor.
Member Function Documentation
◆ addListener()
Registers a listener that will be called when the scrollbar is moved.
◆ autoHides()
|
noexcept |
Returns true if this scrollbar is set to auto-hide when its thumb is as big as its maximum range.
- See also
- setAutoHide
◆ createAccessibilityHandler()
|
overrideprivatevirtual |
Override this method to return a custom AccessibilityHandler for this component.
The default implementation creates and returns a AccessibilityHandler object with an unspecified role, meaning that it will be visible to accessibility clients but without a specific role, action callbacks or interfaces. To control how accessibility clients see and interact with your component subclass AccessibilityHandler, implement the desired behaviours, and return an instance of it from this method in your component subclass.
The accessibility handler you return here is guaranteed to be destroyed before its Component, so it's safe to store and use a reference back to the Component inside the AccessibilityHandler if necessary.
- See also
- getAccessibilityHandler
Reimplemented from juce::Component.
◆ getCurrentRange()
|
inlinenoexcept |
Returns the current thumb range.
- See also
- getCurrentRange, setCurrentRange
◆ getCurrentRangeSize()
|
inlinenoexcept |
Returns the current size of the thumb.
- See also
- getCurrentRange, setCurrentRange
◆ getCurrentRangeStart()
|
inlinenoexcept |
Returns the position of the top of the thumb.
- See also
- getCurrentRange, setCurrentRangeStart
◆ getMaximumRangeLimit()
|
inlinenoexcept |
Returns the upper value that the thumb can be set to.
This is the value set by setRangeLimits().
◆ getMinimumRangeLimit()
|
inlinenoexcept |
Returns the lower value that the thumb can be set to.
This is the value set by setRangeLimits().
◆ getRangeLimit()
|
inlinenoexcept |
Returns the current limits on the thumb position.
- See also
- setRangeLimits
◆ getSingleStepSize()
|
inlinenoexcept |
Returns the current step size.
- See also
- setSingleStepSize
◆ getVisibility()
|
privatenoexcept |
◆ handleAsyncUpdate()
|
overrideprivatevirtual |
Called back to do whatever your class needs to do.
This method is called by the message thread at the next convenient time after the triggerAsyncUpdate() method has been called.
Implements juce::AsyncUpdater.
◆ isVertical()
|
inlinenoexcept |
Returns true if the scrollbar is vertical, false if it's horizontal.
◆ keyPressed()
Called when a key is pressed.
When a key is pressed, the component that has the keyboard focus will have this method called. Remember that a component will only be given the focus if its setWantsKeyboardFocus() method has been used to enable this.
If your implementation returns true, the event will be consumed and not passed on to any other listeners. If it returns false, the key will be passed to any KeyListeners that have been registered with this component. As soon as one of these returns true, the process will stop, but if they all return false, the event will be passed upwards to this component's parent, and so on.
The default implementation of this method does nothing and returns false.
- See also
- keyStateChanged, getCurrentlyFocusedComponent, addKeyListener
Reimplemented from juce::Component.
◆ lookAndFeelChanged()
|
overridevirtual |
Called to let the component react to a change in the look-and-feel setting.
When the look-and-feel is changed for a component, this will be called in all its child components, recursively.
It can also be triggered manually by the sendLookAndFeelChange() method, in case an application uses a LookAndFeel class that might have changed internally.
- See also
- sendLookAndFeelChange, getLookAndFeel
Reimplemented from juce::Component.
◆ mouseDown()
|
overridevirtual |
Called when a mouse button is pressed.
The MouseEvent object passed in contains lots of methods for finding out which button was pressed, as well as which modifier keys (e.g. shift, ctrl) were held down at the time.
Once a button is held down, the mouseDrag method will be called when the mouse moves, until the button is released.
- Parameters
-
Event details about the position and status of the mouse event, including the source component in which it occurred
- See also
- mouseUp, mouseDrag, mouseDoubleClick, contains
Reimplemented from juce::Component.
◆ mouseDrag()
|
overridevirtual |
Called when the mouse is moved while a button is held down.
When a mouse button is pressed inside a component, that component receives mouseDrag callbacks each time the mouse moves, even if the mouse strays outside the component's bounds.
- Parameters
-
Event details about the position and status of the mouse event, including the source component in which it occurred
- See also
- mouseDown, mouseUp, mouseMove, contains, setDragRepeatInterval
Reimplemented from juce::Component.
◆ mouseUp()
|
overridevirtual |
Called when a mouse button is released.
A mouseUp callback is sent to the component in which a button was pressed even if the mouse is actually over a different component when the button is released.
The MouseEvent object passed in contains lots of methods for finding out which buttons were down just before they were released.
- Parameters
-
Event details about the position and status of the mouse event, including the source component in which it occurred
- See also
- mouseDown, mouseDrag, mouseDoubleClick, contains
Reimplemented from juce::Component.
◆ mouseWheelMove()
|
overridevirtual |
Called when the mouse-wheel is moved.
This callback is sent to the component that the mouse is over when the wheel is moved.
If not overridden, a component will forward this message to its parent, so that parent components can collect mouse-wheel messages that happen to child components which aren't interested in them. (Bear in mind that if you attach a component as a mouse-listener to other components, then those wheel moves will also end up calling this method and being passed up to the parents, which may not be what you intended to happen).
- Parameters
-
Event details about the mouse event wheel details about the mouse wheel movement
Reimplemented from juce::Component.
◆ moveScrollbarInPages()
| bool juce::ScrollBar::moveScrollbarInPages | ( | int | howManyPages, |
| NotificationType | notification = sendNotificationAsync ) |
Moves the scroll bar up or down in pages.
This will move the bar by a multiple of its current thumb size, effectively doing a page-up or down.
A positive value here will move the bar down or to the right, a negative value moves it up or to the left.
- Parameters
-
howManyPages the number of pages to move the scrollbar notification whether to send a notification of the change to listeners. A notification will only be sent if the position has changed.
- Returns
- true if the scrollbar's position actually changed.
◆ moveScrollbarInSteps()
| bool juce::ScrollBar::moveScrollbarInSteps | ( | int | howManySteps, |
| NotificationType | notification = sendNotificationAsync ) |
Moves the scrollbar by a number of single-steps.
This will move the bar by a multiple of its single-step interval (as specified using the setSingleStepSize() method).
A positive value here will move the bar down or to the right, a negative value moves it up or to the left.
- Parameters
-
howManySteps the number of steps to move the scrollbar notification whether to send a notification of the change to listeners. A notification will only be sent if the position has changed.
- Returns
- true if the scrollbar's position actually changed.
◆ paint()
Components can override this method to draw their content.
The paint() method gets called when a region of a component needs redrawing, either because the component's repaint() method has been called, or because something has happened on the screen that means a section of a window needs to be redrawn.
Any child components will draw themselves over whatever this method draws. If you need to paint over the top of your child components, you can also implement the paintOverChildren() method to do this.
If you want to cause a component to redraw itself, this is done asynchronously - calling the repaint() method marks a region of the component as "dirty", and the paint() method will automatically be called sometime later, by the message thread, to paint any bits that need refreshing. In JUCE (and almost all modern UI frameworks), you never redraw something synchronously.
You should never need to call this method directly - to take a snapshot of the component you could use createComponentSnapshot() or paintEntireComponent().
- Parameters
-
g the graphics context that must be used to do the drawing operations.
- See also
- repaint, paintOverChildren, Graphics
Reimplemented from juce::Component.
◆ parentHierarchyChanged()
|
overridevirtual |
Called to indicate that the component's parents have changed.
When a component is added or removed from its parent, this method will be called on all of its children (recursively - so all children of its children will also be called as well).
Subclasses can override this if they need to react to this in some way.
- See also
- getParentComponent, isShowing, ComponentListener::componentParentHierarchyChanged
Reimplemented from juce::Component.
◆ removeListener()
Deregisters a previously-registered listener.
◆ resized()
|
overridevirtual |
Called when this component's size has been changed.
A component can implement this method to do things such as laying out its child components when its width or height changes.
The method is called synchronously as a result of the setBounds or setSize methods, so repeatedly changing a components size will repeatedly call its resized method (unlike things like repainting, where multiple calls to repaint are coalesced together).
If the component is a top-level window on the desktop, its size could also be changed by operating-system factors beyond the application's control.
- See also
- moved, setSize
Reimplemented from juce::Component.
◆ scrollToBottom()
| bool juce::ScrollBar::scrollToBottom | ( | NotificationType | notification = sendNotificationAsync | ) |
Scrolls to the bottom (or right). This is the same as calling setCurrentRangeStart (getMaximumRangeLimit() - getCurrentRangeSize());
- Parameters
-
notification whether to send a notification of the change to listeners. A notification will only be sent if the position has changed.
- Returns
- true if the scrollbar's position actually changed.
◆ scrollToTop()
| bool juce::ScrollBar::scrollToTop | ( | NotificationType | notification = sendNotificationAsync | ) |
Scrolls to the top (or left). This is the same as calling setCurrentRangeStart (getMinimumRangeLimit());
- Parameters
-
notification whether to send a notification of the change to listeners. A notification will only be sent if the position has changed.
- Returns
- true if the scrollbar's position actually changed.
◆ setAutoHide()
| void juce::ScrollBar::setAutoHide | ( | bool | shouldHideWhenFullRange | ) |
Tells the scrollbar whether to make itself invisible when not needed.
The default behaviour is for a scrollbar to become invisible when the thumb fills the whole of its range (i.e. when it can't be moved). Setting this value to false forces the bar to always be visible.
- See also
- autoHides()
◆ setButtonRepeatSpeed()
| void juce::ScrollBar::setButtonRepeatSpeed | ( | int | initialDelayInMillisecs, |
| int | repeatDelayInMillisecs, | ||
| int | minimumDelayInMillisecs = -1 ) |
Changes the delay before the up and down buttons autorepeat when they are held down.
For an explanation of what the parameters are for, see Button::setRepeatSpeed().
- See also
- Button::setRepeatSpeed
◆ setCurrentRange() [1/2]
| void juce::ScrollBar::setCurrentRange | ( | double | newStart, |
| double | newSize, | ||
| NotificationType | notification = sendNotificationAsync ) |
Changes the position of the scrollbar's 'thumb'.
This sets both the position and size of the thumb - to just set the position without changing the size, you can use setCurrentRangeStart().
- Parameters
-
newStart the top (or left) of the thumb, in the range getMinimumRangeLimit() <= newStart <= getMaximumRangeLimit(). If the value is beyond these limits, it will be clipped. newSize the size of the thumb, such that getMinimumRangeLimit() <= newStart + newSize <= getMaximumRangeLimit(). If the size is beyond these limits, it will be clipped. notification specifies if and how a callback should be made to any listeners if the range actually changes
- See also
- setCurrentRangeStart, getCurrentRangeStart, getCurrentRangeSize
◆ setCurrentRange() [2/2]
| bool juce::ScrollBar::setCurrentRange | ( | Range< double > | newRange, |
| NotificationType | notification = sendNotificationAsync ) |
Changes the position of the scrollbar's 'thumb'.
This sets both the position and size of the thumb - to just set the position without changing the size, you can use setCurrentRangeStart().
If this method call actually changes the scrollbar's position, it will trigger an asynchronous call to ScrollBar::Listener::scrollBarMoved() for all the listeners that are registered.
The notification parameter can be used to optionally send or inhibit a callback to any scrollbar listeners.
- Returns
- true if the range was changed, or false if nothing was changed.
- See also
- getCurrentRange. setCurrentRangeStart
◆ setCurrentRangeStart()
| void juce::ScrollBar::setCurrentRangeStart | ( | double | newStart, |
| NotificationType | notification = sendNotificationAsync ) |
Moves the bar's thumb position.
This will move the thumb position without changing the thumb size. Note that the maximum thumb start position is (getMaximumRangeLimit() - getCurrentRangeSize()).
If this method call actually changes the scrollbar's position, it will trigger an asynchronous call to ScrollBar::Listener::scrollBarMoved() for all the listeners that are registered.
- See also
- setCurrentRange
◆ setOrientation()
| void juce::ScrollBar::setOrientation | ( | bool | shouldBeVertical | ) |
Changes the scrollbar's direction.
You'll also need to resize the bar appropriately - this just changes its internal layout.
- Parameters
-
shouldBeVertical true makes it vertical; false makes it horizontal.
◆ setRangeLimits() [1/2]
| void juce::ScrollBar::setRangeLimits | ( | double | minimum, |
| double | maximum, | ||
| NotificationType | notification = sendNotificationAsync ) |
Sets the minimum and maximum values that the bar will move between.
The bar's thumb will always be constrained so that the entire thumb lies within this range.
- Parameters
-
minimum the new range minimum. maximum the new range maximum. notification whether to send a notification of the change to listeners. A notification will only be sent if the range has changed.
- See also
- setCurrentRange
◆ setRangeLimits() [2/2]
| void juce::ScrollBar::setRangeLimits | ( | Range< double > | newRangeLimit, |
| NotificationType | notification = sendNotificationAsync ) |
Sets the minimum and maximum values that the bar will move between.
The bar's thumb will always be constrained so that the entire thumb lies within this range.
- Parameters
-
newRangeLimit the new range. notification whether to send a notification of the change to listeners. A notification will only be sent if the range has changed.
- See also
- setCurrentRange
◆ setSingleStepSize()
|
noexcept |
Sets the amount by which the up and down buttons will move the bar.
The value here is in terms of the total range, and is added or subtracted from the thumb position when the user clicks an up/down (or left/right) button.
◆ setVisible()
|
overridevirtual |
Makes the component visible or invisible.
This method will show or hide the component. Note that components default to being non-visible when first created. Also note that visible components won't be seen unless all their parent components are also visible.
This method will call visibilityChanged() and also componentVisibilityChanged() for any component listeners that are interested in this component.
- Parameters
-
shouldBeVisible whether to show or hide the component
- See also
- isVisible, isShowing, visibilityChanged, ComponentListener::componentVisibilityChanged
Reimplemented from juce::Component.
◆ timerCallback()
|
overrideprivatevirtual |
The user-defined callback routine that actually gets called periodically.
It's perfectly ok to call startTimer() or stopTimer() from within this callback to change the subsequent intervals.
Implements juce::Timer.
◆ updateThumbPosition()
|
private |
Member Data Documentation
◆ autohides
|
private |
◆ downButton
|
private |
◆ dragStartMousePos
|
private |
◆ dragStartRange
|
private |
◆ initialDelayInMillisecs
|
private |
◆ isDraggingThumb
|
private |
◆ lastMousePos
|
private |
◆ listeners
|
private |
◆ minimumDelayInMillisecs
|
private |
◆ repeatDelayInMillisecs
|
private |
◆ singleStepSize
|
private |
◆ thumbAreaSize
|
private |
◆ thumbAreaStart
|
private |
◆ thumbSize
|
private |
◆ thumbStart
|
private |
◆ totalRange
|
private |
◆ upButton
|
private |
◆ userVisibilityFlag
|
private |
◆ vertical
|
private |
◆ visibleRange
|
private |
The documentation for this class was generated from the following files:
- /home/runner/work/lmms-fork/lmms-fork/plugins/CarlaBase/carla/source/modules/juce_gui_basics/layout/juce_ScrollBar.h
- /home/runner/work/lmms-fork/lmms-fork/plugins/CarlaBase/carla/source/modules/juce_gui_basics/layout/juce_ScrollBar.cpp
Generated on for LMMS by
1.16.1
